用途:用于织造服装、毛绒玩具、毛毯及装饰布等织物。
Application: This Machine is for producing of high-quality blankets, dress tufts toy and upholstery fabrics etc.
特点:开式大凸轮摆臂传动机构,地梳固定不摆动,便易式沉降机构,带耳沉降片穿防闭钢丝,毛绒纱可直接用线架供线,绒高8-30mm
Characteristics: Open connecting wheel system which is fixed to subside easily subside wire piece provided plush yarns, the plush is 8-30mm.
主要技术参数:
Main technical specification:
针型:舌针
Working needle: latch needle
机号:E12, E14, E16,E18
E22Gauge: E12, E14, E16, E18, E22
梳栉数:5把 6把
Number of guide bars: 5、6
脱圈板间距:16-60mmKnock-over coml.
Bar distance: 16-60mm
工作门幅:138″ 154″ 190″
Working widths: 138″ 154″ 190″
|
